NAUTECH 1.2/M-90 hydraulic set outboard up to 300hp including 9 meter hose (UC128-OBF/2)

This set is suitable for most outboard motors up to 300HP on the market. The set contains all the elements to replace or install a new hydraulic or mechanical set. Including 9 meters of custom-made hose including fittings.NAUTECH™ outboard set hydraulic steering system up to 300HP consists of:



UP28F steering pump
UC128-OBF/1 (75244005)/ UC128-OBF/2 (75244008) (for compatibility table see page ..)
OL150 2L hydraulic oil
KIT OB/M90 hose kit (2 x 9 meter hose)
Number of wheel turns 4.3The UP28 steering pump is equipped with a built-in non-return valve, which prevents backlash from the engine in the hydraulic system. The pump is also equipped with a bypass valve that ensures that overpressure in the pump is prevented, so that no damage occurs.Technical information UP28F
Oil displacement 28cc
5 plungers
Maximum recommended handlebar size diameter Ø 710mmTechnical information UC128-OBF1/2
Volume 120cc
Working pressure 450kg
Internal diameter Ø 35mm
Stroke 185mm
Hose connection 3/8"Please note! Depending on the application, the UC128-OBF is available in three versions: UC128-OBF/1, UC128-OBF/2 and UC128-OBF/3 (on request). For compatibility, see the table on page ...
